Designed for Existing
Filter Control Systems:
Modern
Obsolete
Manual
  • Low-cost patented filter backwash optimization system for existing filter control systems.
  • Works in conjunction with modern, obsolete or completely manual filter control systems
  • Wireless Filter Backwash Optimization System that precisely monitors bed expansion and backwash flow duration.
  • Wireless communication through smart mobile phones and tablets.
  • Helps eliminates excess backwash water thereby increasing water production
  • Upgrades to Filter Magic® Zero2Waste® systems
Mark Romers

President of Filter Magic

What’s one minute worth?

A plant with eight (8) filters and an average runtime of 70 hours will require 1,000 backwashes annually. If IQ helps this plant save just one minute during every backwash at 5,000 GPM, this would save the plant more than 5,000,000 gallons of water annually.

Depending on the condition of an existing filter system, filter control system, and operational procedures, it is possible to save tens of millions of gallons of water annually.

Water plant gravity filter systems grow dirty over time, prompting a need to be backwashed periodically. During the backwash procedure, the most critical action is the highwash step. During the highwash, a maximum backwash flow rate is applied to the media to wash away the suspended solids collected within the media. Many times the highwash duration is longer than necessary to effectively clean the media. When this happens, the ripening, or seasoning, in the media is stripped away causing excessive rewash, or filter-to-waste, durations when returning a filter to service.

Zero2Waste® IQ was designed as a low-cost solution to provide operations with the information necessary to fine tune existing filter control systems to achieve the most efficient highwash duration. When efficient high washes are achieved, it is possible for a utility to save a substantial amount of water and money over time.

  • Continuous monitoring of filter media level at all times, especially during a backwash, allowing our filter backwash system to precisely control the filter media bed expansion during the high wash regardless of water temperature.

  • Enhanced filter system performance and efficiency.

  • Historical data and analysis of long term filter performance,

  • Reduction in cost of wastewater treatment systems.

  • Increase in water production



Water... Every Drop Counts

Filter Backwash Optimization System

Water Treatment Plant Solution

The Zero2Waste® IQ System is a low-cost, easy-to-use, easy-to-install, secure, innovative and intelligent gravity filter backwash optimization system. IQ analyzes each backwash, interacts with operations through their mobile phones or tablets and provides them critical information allowing fine tuning of filter backwashes for maximum performance and efficiency.

While traditional filter control systems use backwash flow rate and time to highwash filters, IQ uses backwash turbidity and media bed expansion to control the highwash.

Traditional technology and methods do not provide operations live accurate information to clearly understand if the backwash flow rate is properly fluidizing the media or when to terminate the highwash. Yet, this information is critical to ensure that the media is not over washed and water is not wasted.

IQ provides operations continuous accurate data needed to fine tune the highwash for a precise media bed expansion, backwash turbidity truncation, typically 20 NTU. With this critical information, operations may substantially improve filter backwash performance and efficiency without wasting water.

How an IQ System Works

The Zero2Waste® IQ System utilizes new innovative instrumentation located inside the filters at trough height that constantly monitors and analyzes turbidity and media level.

When filters are in service, the Z2W® IQ System provides media level, media level loss alarms, and influent turbidity.

When filters are being backwashed, the system provides media bed expansion and backwash turbidity (mud boil). IQ also monitors existing filter’s effluent turbidity and backwash flow.

During a backwash, all of the previously mentioned data is available to operations through the interactive IQ browser on their smart mobile phones or tablets. Operators use the browser to enter existing operational parameters used to control their backwashes, such as media level, highwash flow rates and durations. Operators also enter desired media bed expansion (20%) and highwash turbidity truncation (20 NTU) as backwash control goals.

Once these steps are completed, a backwash is then performed and IQ analyzes all of the data. Reports are displayed on the browser which then informs the operators of performance deviations within the preset set points. With this knowledge, operators can make adjustments to their filter control system to increase or decrease the highwash flow rate set point and highwash duration to achieve desired media bed expansion and backwash truncation. After 2 to 3 backwashes, the changes made to the control system will provide enhanced backwash performance, leave the media ripened after a backwash, mitigate the effluent turbidity spike, reduce the rewash process and will save water.

A full mud boil at the height of a high wash

As the mud boil dissipates and turbidity falls toward 20 NTU

A clean filter

The Zero2Waste® IQ Solution

IQ is specifically designed to be fully incorporated into a future Filter Magic® Zero2Waste® filter control system when the Utility decides to move forward to upgrade existing filter control systems. Thus saving the Utility money at the time of the upgrade.
